| Vertical Rj45 Connector Product Information |
| Part Number | V8BR-1AX1-GH |
| Part Status | Active |
| Connector Type | RJ45 |
| Cores per Port | 4 |
| LED Option | Green/Yellow |
| Number of Ports | 1X1 |
| Orientation | Vertical |
| Shielding | shielded |
| Speed | 1000 BASE-T |
| Temperature | -40 to 85°C |
| Termination | Solder |
| Mounting Type | Panel Mount, Through Hole |
| PCB Mount Angle | SIDE ENTRY |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Diodes | NO DIODES |
| AutomDX | YES |
| You may be interesting in below considerate supports: |
| Datasheet | Request by email to | contact us |
| Samples | Free | For Free samples delivery, pls advise below infomation For Shipping |
| Company Name | |
| Delivery Address | |
| Telephone Number | |
| Contact Person | |
| UPS/DHL/Fedex/TNT A.C | (If available) |
| Trial Production | U/P(USD) | $0.09-$1.85 | We can ship out parts directly to your warehouse/door to door |
| L/T(Weeks) | Stock |
| Shipping Term | DAP/CIF/FCA/FOB |
| Mass Production | U/P(USD) | Stock | |
| L/T(Weeks) | Stock |
| Shipping Term | DAP/CIF/FCA/FOB |
| Lifecycel | More than 20 years | You can use our parts for long term consideration |
| Reject Ratio | Zero Defective (100% Tested) |
| Special Services | Accept customized service | Accept revised designing |
| Now you can contact us instantly |
V8BR-1AX1-GH Single Port Vertical Rj45 Connctor Package:
Package:Tray N.W/pcs:0.008kg
SPQ:50pcs Qty/carton:1000pcs
Carton size:32*30*31cm G.W./carton:8kg
